Chainflex 3G-OTH-47433 — Technical Specifications

Name: Chainflex 3G-OTH-47433 CHAINFLEX Bus Cable: (3) 18 AWG (0.75)/(1) Pr 24 AWG (0.25), TPR, Order by the Foot, Profibus, Red (MPN CFBUS-003). Key specifications — Conductor Grouping: (3) 18 AWG/(1) Pair 24 AWG; Minimum Bend Radius Factor - Fixed: 5 x OD; Minimum Bend Radius Factor - Flexible: 8 x OD; Shielding: Shielded; Brand: CHAINFLEX.
Brand: Chainflex

The CHAINFLEX Bus Cable (SKU 801MA5) is a shielded continuous flexing bus drop cable with a conductor grouping of (3) 18 AWG/(1) Pair 24 AWG. It features a minimum bend radius factor of 5 x OD for fixed installations and 8 x OD for flexible applications. This Profibus cable is available by the foot in red (MPN CFBUS-003).

View Product & Quote

Technical Specifications

Parameter	Value
Type	TPR, Order by the Foot, Profibus, Red
Brand	CHAINFLEX
Shielding	Shielded
Conductor Grouping	(3) 18 AWG/(1) Pair 24 AWG
Manufacturer Part Number	CFBUS-003
Minimum Bend Radius Factor - Fixed	5 x OD
Minimum Bend Radius Factor - Flexible	8 x OD
