Chainflex 3G-OTH-47301 — Technical Specifications

Name: Chainflex 3G-OTH-47301 CHAINFLEX Motor Cable: 6 AWG, 1 Conductors, Order by the Foot, PVC Jacket, 600 V (MPN CF885-60-01). Key specifications — Conductor Material: Copper; Conductor Configuration: Single; Minimum Bend Radius Factor - Fixed: 8 x OD; Minimum Bend Radius Factor - Flexible: 12 x OD; Includes Ground: No; Minimum Bend Radius Factor - E-Chain: 15 x OD; Resistance Properties: Flame Retardant; Standards: FT-1.
Brand: Chainflex

The CHAINFLEX Motor Cable (CF885-60-01) is a continuous flexing power cable from the Chainflex series, featuring a single 6 AWG copper conductor with a PVC jacket rated at 600 V. It is flame retardant (FT-1 standard) and does not include a ground conductor. Minimum bend radius factors are 8 x OD for fixed installation, 12 x OD for flexible use, and 15 x OD for e-chain applications.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	CHAINFLEX
Series	Chainflex
Standards	FT-1
Cable Series	CF885
Product Type	Motor Cable
Includes Ground	No
Conductor Material	Copper
Resistance Properties	Flame Retardant
Conductor Configuration	Single
Manufacturer Part Number	CF885-60-01
Minimum Bend Radius Factor - Fixed	8 x OD
Minimum Bend Radius Factor - E-Chain	15 x OD
Minimum Bend Radius Factor - Flexible	12 x OD
