Chainflex 3G-OTH-46780 — Technical Specifications

Name: Chainflex 3G-OTH-46780 CHAINFLEX Bus Cable: (1) Pr 18 AWG/(1) Pr 15 AWG, TPR, Order by the Foot, Device Net, Purple (MPN CFBUS-031-1). Key specifications — Bus System: Device Net; Conductor Grouping: (1) Pair 18 AWG/(1) Pair 15 AWG; Minimum Bend Radius Factor - Fixed: 5 x OD; Minimum Bend Radius Factor - Flexible: 8 x OD; Shielding: Shielded; Brand: CHAINFLEX.
Brand: Chainflex

The CHAINFLEX Bus Cable (SKU 24C170, MPN CFBUS-031-1) is a shielded continuous-flexing bus drop cable for Device Net systems. It features a conductor grouping of (1) Pair 18 AWG/(1) Pair 15 AWG and a minimum bend radius factor of 5 x OD for fixed installation and 8 x OD for flexible applications.

View Product & Quote

Technical Specifications

Parameter	Value
Type	TPR, Order by the Foot, Device Net, Purple
Brand	CHAINFLEX
Shielding	Shielded
Bus System	Device Net
Conductor Grouping	(1) Pair 18 AWG/(1) Pair 15 AWG
Manufacturer Part Number	CFBUS-031-1
Minimum Bend Radius Factor - Fixed	5 x OD
Minimum Bend Radius Factor - Flexible	8 x OD
