Carling Technologies 3G-OTH-34881 — Technical Specifications

Name: Carling Technologies 3G-OTH-34881 CARLING TECHNOLOGIES Lighted Rocker Switch: 2 Positions, SPST, On/Off, Red (MPN LTILA51-6S-BL-RC-NBL/125N). Key specifications — AC Contact Rating: 15 A @ 125 V; DC Contact Rating: 15 A @ 15 to 28 V; Horsepower: 1/2 hp @ 125 to 250 V; NEMA Enclosure Rating: No Enclosure; Operator Illumination: Illuminated; Switch Color: Red; Terminal Connection Type: 0.25 in Quick Connect Tab; Includes Lamp Module: No Lamp Module Included.
Brand: Carling Technologies

The CARLING TECHNOLOGIES Lighted Rocker Switch (MPN LTILA51-6S-BL-RC-NBL/125N) is a general-purpose rocker switch from the LTIL series. It is a SPST, 2-position On/Off switch with a red illuminated operator and includes a lens. Key specifications include an AC contact rating of 15 A @ 125 V, a DC contact rating of 15 A @ 15 to 28 V, and a horsepower rating of 1/2 hp @ 125 to 250 V, with a 0.25 in Quick Connect Tab terminal connection.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	CARLING TECHNOLOGIES
Series	LTIL
Horsepower	1/2 hp @ 125 to 250 V
Switch Color	Red
Includes Lens	Lens Included
Displayed Brand	CARLING TECHNOLOGIES
AC Contact Rating	15 A @ 125 V
DC Contact Rating	15 A @ 15 to 28 V
Includes Lamp Module	No Lamp Module Included
NEMA Enclosure Rating	No Enclosure
Operator Illumination	Illuminated
Manufacturer Part Number	LTILA51-6S-BL-RC-NBL/125N
Terminal Connection Type	0.25 in Quick Connect Tab
