Bussmann 3G-OTH-23506 — Technical Specifications
The BUSSMANN Universal Surge Protection Device is a single-phase DIN Rail internal-mount data and signal SPD (SKU 20AZ43, MPN BSPD24DING). It operates at 24V DC with a maximum continuous operating voltage of 33 V DC, protecting L-L modes with a voltage protection rating of 102V (L-L). This 4-wire, 4-pole unit features a polyamide enclosure and no filtering.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 24V |
| Type | L-G/L-L |
| Brand | BUSSMANN |
| Poles | 4 |
| Wires | 4 |
| Voltage | 24V DC |
| Filtering | No |
| Mounting Style | DIN-Rail |
| Number Of Wires | 4 Wires |
| Enclosure Material | Polyamide |
| Modes Of Protection | L-L |
| Manufacturer Part Number | BSPD24DING |
| Voltage Protection Rating | 102V (L-L) |
| Max. Continuing Operating Voltage | 33 V DC |
