Brad Harrison 3G-OTH-48492 — Technical Specifications
The BRAD HARRISON Cordset: M8 Male Straight X M8 Female Straight is a double-ended cordset with a PVC jacket for flexing applications. It features a 5 m cable length, 24 AWG wire size, and 3 pins, with an M8 male straight connector on one end and an M8 female straight connector on the other. The yellow PVC jacket provides an IP67 and NEMA 6P rating.
Technical Specifications
| Parameter | Value |
|---|---|
| Pins | 3 |
| Type | Yellow, PVC |
| Brand | BRAD HARRISON |
| Cable Lg | 5 m |
| IP Rating | IP67 |
| Wire Size | 24 AWG |
| NEMA Rating | 6P |
| End 1 Gender | Male |
| End 2 Gender | Female |
| Cable Jacket Color | Yellow |
| Cable Jacket Material | PVC |
| End 1 Connection Type | M8 |
| End 2 Connection Type | M8 |
| Manufacturer Part Number | 443030A10M050 |
| End 1 Mounting Orientation | Straight |
| End 2 Mounting Orientation | Straight |
