Ashcroft 3G-OTH-176530 — Technical Specifications
The ASHCROFT Series A4 General Industrial Pressure Transducer is a pressure transmitter with cable and wire leads, offering a 0 psi to 300 psi range and a 4 to 20mA DC output. It features ±0.25% accuracy, an IP65 and NEMA 4X rating, stainless steel housing, and a 1/4 in Male NPT process connection. Overpressure is 1.5x range, burst pressure is 2x range, and a NIST-traceable calibration certificate is included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Type | Cable |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | A4 |
| Accuracy | ±0.25% |
| Male NPT | 1/4 in |
| IP Rating | IP65 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| Burst Pressure | 2x Range |
| Housing Material | Stainless Steel |
| Electrical Connections | Cable |
| Process Connection Type | NPT |
| Manufacturer Part Number | A4SAM0242F2300#G |
| Process Connection Gender | Male |
| Calibration Certificate Included | NIST-Traceable Calibration Certificate Included |
