Ashcroft 3G-OTH-176445 — Technical Specifications

Name: Ashcroft 3G-OTH-176445 Pressure Transmitter: 0 psi to 100 psi, 4 to 20mA DC, 1/2 in NPT Conduit with Cable, 1/4 in Male NPT (MPN E2GB7NM0242CCX03F100#). Key specifications — Accuracy: ±1%; NEMA Rating: 4X; Burst Pressure: 8x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP66; Housing Material: Stainless Steel; Electrical Connections: 1/2 in NPT Conduit with Cable; Output: 4 to 20mA DC.
Brand: Ashcroft

The ASHCROFT E2G Series Pressure Transmitter (0 psi to 100 psi) is a stainless-steel pressure transmitter with a 4 to 20mA DC output, ±1% accuracy, and IP66/NEMA 4X rating. It features a 1/2 in NPT conduit with cable electrical connection and a 1/4 in Male NPT process connection, with overpressure of 1.5x range and burst pressure of 8x range.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Brand	ASHCROFT
Output	4 to 20mA DC
Series	E2G
Accuracy	±1%
Male NPT	1/4 in
IP Rating	IP66
NEMA Rating	4X
Overpressure	1.5x Range
Burst Pressure	8x Range
Housing Material	Stainless Steel
Electrical Connections	1/2 in NPT Conduit with Cable
NPT Conduit With Cable	1/2 in
Process Connection Type	NPT
Manufacturer Part Number	E2GB7NM0242CCX03F100#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
