Ashcroft 3G-OTH-176398 — Technical Specifications
The ASHCROFT E2G Series Pressure Transmitter (0 psi to 50 psi) is a pressure transmitter with cable and wire leads, featuring a 4 to 20mA DC output and ±1% accuracy. It has an IP66 and NEMA 4X rating, a stainless steel housing, and a 1/2 in NPT conduit with cable electrical connection. The transmitter offers an overpressure of 2.2x range and a burst pressure of 8x range, with a 1/4 in male NPT process connection.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | E2G |
| Accuracy | ±1% |
| Male NPT | 1/4 in |
| IP Rating | IP66 |
| NEMA Rating | 4X |
| Overpressure | 2.2x Range |
| Burst Pressure | 8x Range |
| Housing Material | Stainless Steel |
| Electrical Connections | 1/2 in NPT Conduit with Cable |
| NPT Conduit With Cable | 1/2 in |
| Process Connection Type | NPT |
| Manufacturer Part Number | E2GB7NM0242CCX03F50# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
