Ashcroft 3G-OTH-176399 — Technical Specifications
The ASHCROFT E2G Series Pressure Transmitter (0 psi to 15 psi, SKU 797RU2) is a pressure transmitter with cable and wire leads, featuring a 4 to 20mA DC output, ±1% accuracy, and a stainless steel housing. It has an IP65 and NEMA 4X rating, with a 1/2 in NPT conduit with cable electrical connection and a 1/4 in male NPT process connection. Overpressure is 2x range, burst pressure is 5x range, and no NIST-traceable calibration certificate is included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | E2G |
| Accuracy | ±1% |
| Male NPT | 1/4 in |
| IP Rating | IP65 |
| NEMA Rating | 4X |
| Overpressure | 2x Range |
| Burst Pressure | 5x Range |
| Housing Material | Stainless Steel |
| Electrical Connections | 1/2 in NPT Conduit with Cable |
| NPT Conduit With Cable | 1/2 in |
| Process Connection Type | NPT |
| Manufacturer Part Number | E2GC7NM0242CCX03F15# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
