Ashcroft 3G-OTH-176460 — Technical Specifications
The ASHCROFT E2G Series Pressure Transmitter (SKU 797RR3) is a pressure transmitter with cable and wire leads, offering a 0 psi to 150 psi range and a 4 to 20mA DC output. It features ±0.25% accuracy, an IP66 and NEMA 4X rating, a stainless steel housing, and a 1/2 in NPT conduit with cable electrical connection. The transmitter includes a NIST-traceable calibration certificate and has a burst pressure of 8x range.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | E2G |
| Accuracy | ±0.25% |
| Male NPT | 1/4 in |
| IP Rating | IP66 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| Burst Pressure | 8x Range |
| Housing Material | Stainless Steel |
| Electrical Connections | 1/2 in NPT Conduit with Cable |
| NPT Conduit With Cable | 1/2 in |
| Process Connection Type | NPT |
| Manufacturer Part Number | E2GB3CM0242CCX03F150# |
| Process Connection Gender | Male |
| Calibration Certificate Included | NIST-Traceable Calibration Certificate Included |
