Ashcroft 3G-OTH-176526 — Technical Specifications
The ASHCROFT E2G Series Pressure Transmitter (SKU 797RR1) is a pressure transmitter with cable and wire leads, offering a 0 psi to 100 psi range and a 4 to 20mA DC output. It features an accuracy of ±0.25%, an IP66 and NEMA 4X rating, and a stainless steel housing. The unit includes a 1/2 in NPT conduit with cable electrical connection and a 1/4 in Male NPT process connection, with a NIST-Traceable Calibration Certificate included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | E2G |
| Accuracy | ±0.25% |
| Male NPT | 1/4 in |
| IP Rating | IP66 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| Burst Pressure | 8x Range |
| Housing Material | Stainless Steel |
| Electrical Connections | 1/2 in NPT Conduit with Cable |
| NPT Conduit With Cable | 1/2 in |
| Process Connection Type | NPT |
| Manufacturer Part Number | E2GB3CM0242CCX03F100# |
| Process Connection Gender | Male |
| Calibration Certificate Included | NIST-Traceable Calibration Certificate Included |
