Ashcroft 3G-OTH-176498 — Technical Specifications
The ASHCROFT E2G Series Pressure Transmitter (0 psi to 30 psi) is a pressure transmitter with cable and wire leads, featuring a 4 to 20mA DC output and ±0.25% accuracy. It has a stainless steel housing, IP66 and NEMA 4X ratings, 1/2 in NPT conduit with cable electrical connections, and a 1/4 in male NPT process connection. Overpressure is 1.5x range, burst pressure is 8x range, and a NIST-traceable calibration certificate is included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | E2G |
| Accuracy | ±0.25% |
| Male NPT | 1/4 in |
| IP Rating | IP66 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| Burst Pressure | 8x Range |
| Housing Material | Stainless Steel |
| Electrical Connections | 1/2 in NPT Conduit with Cable |
| NPT Conduit With Cable | 1/2 in |
| Process Connection Type | NPT |
| Manufacturer Part Number | E2GB3CM0242CCX03F30# |
| Process Connection Gender | Male |
| Calibration Certificate Included | NIST-Traceable Calibration Certificate Included |
