Ashcroft 3G-OTH-176528 — Technical Specifications
The ASHCROFT G2 Series Pressure Transmitter (0 psi to 30 psi, 1 to 5V DC output) is a pressure transmitter with cable and wire leads. It features a nylon housing, a 7/16 in male SAE process connection, and IP67 / NEMA 4X ratings. Key supplied specifications include ±0.5% accuracy, 2x range overpressure, and 10x range burst pressure.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 1 to 5V |
| Type | Cable & Wire Leads, IP67 /4X |
| Brand | ASHCROFT |
| Output | 1 to 5V DC |
| Series | G2 |
| Accuracy | ±0.5% |
| Male SAE | 7/16 in |
| IP Rating | IP67 |
| NEMA Rating | 4X |
| Overpressure | 2x Range |
| Burst Pressure | 10x Range |
| Housing Material | Nylon |
| Process Connection Type | SAE |
| Manufacturer Part Number | G17MEK15F230# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
