Ashcroft 3G-OTH-176283 — Technical Specifications
The ASHCROFT G2 Series Pressure Transmitter with 4-Pin Mini-DIN Connector measures 0 psi to 1,000 psi with a 1 to 5V DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a nylon housing. Overpressure is 2x range, burst pressure is 5x range, and the process connection is SAE male. No NIST-traceable calibration certificate is included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 1 to 5V |
| Type | 4-Pin Mini-DIN Hirschmann G Series Connector |
| Brand | ASHCROFT |
| Output | 1 to 5V DC |
| Series | G2 |
| Accuracy | ±0.5% |
| IP Rating | IP67 |
| NEMA Rating | 4X |
| Overpressure | 2x Range |
| Burst Pressure | 5x Range |
| Housing Material | Nylon |
| Process Connection Type | SAE |
| Manufacturer Part Number | G17MEK15M11000# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
