Ashcroft 3G-OTH-176730 — Technical Specifications
The ASHCROFT G2 Series Pressure Transmitter (SKU 5LRW7) is a pressure transmitter with a 4-pin M12 connector, offering a 0 psi to 5,000 psi range and a 1 to 5V DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, and a nylon housing with a 7/16 in male SAE process connection. Overpressure capability is 1.5x range, with burst pressure at 5x range.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 1 to 5V |
| Brand | ASHCROFT |
| Output | 1 to 5V DC |
| Series | G2 |
| Accuracy | ±0.5% |
| Male SAE | 7/16 in |
| IP Rating | IP67 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| M12 Connector | 4-Pin |
| Burst Pressure | 5x Range |
| Housing Material | Nylon |
| Process Connection Type | SAE |
| Manufacturer Part Number | G17MEK15EW5000# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
