Ashcroft 3G-OTH-176646 — Technical Specifications

Name: Ashcroft 3G-OTH-176646 Pressure Transmitter: 0 psi to 1,000 psi, 1 to 5V DC, 4-Pin M12 Connector, 1/8 in Male NPT, IP66 /4X (MPN G17M0115EW1000#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 5x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP66; Housing Material: Nylon; Output: 1 to 5V DC; Overpressure: 2x Range.
Brand: Ashcroft

The ASHCROFT G2 Pressure Transmitter (0 psi to 1,000 psi) is a pressure transmitter with a 4-Pin M12 Connector, featuring a 1 to 5V DC output and 1/8 in Male NPT process connection. It offers ±0.5% accuracy, an IP66 and NEMA 4X rating, and a nylon housing. Overpressure capacity is 2x range, with burst pressure at 5x range.

View Product & Quote

Technical Specifications

Parameter	Value
DC	1 to 5V
Type	IP66 /4X
Brand	ASHCROFT
Output	1 to 5V DC
Series	G2
Accuracy	±0.5%
Male NPT	1/8 in
IP Rating	IP66
NEMA Rating	4X
Overpressure	2x Range
M12 Connector	4-Pin
Burst Pressure	5x Range
Housing Material	Nylon
Process Connection Type	NPT
Manufacturer Part Number	G17M0115EW1000#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
