Ashcroft 3G-OTH-176644 — Technical Specifications
The ASHCROFT G2 Series Pressure Transmitter (SKU 5LRV2) is a 0 psi to 300 psi pressure transmitter with a 4-Pin M12 Connector and a 1 to 5V DC output. It features an accuracy of ±0.5%, an IP66 and NEMA 4X rating, a nylon housing, and a 1/8 in Male NPT process connection. The device offers an overpressure of 2x Range and a burst pressure of 10x Range, with no NIST-traceable calibration certificate included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 1 to 5V |
| Type | IP66 /4X |
| Brand | ASHCROFT |
| Output | 1 to 5V DC |
| Series | G2 |
| Accuracy | ±0.5% |
| Male NPT | 1/8 in |
| IP Rating | IP66 |
| NEMA Rating | 4X |
| Overpressure | 2x Range |
| M12 Connector | 4-Pin |
| Burst Pressure | 10x Range |
| Housing Material | Nylon |
| Process Connection Type | NPT |
| Manufacturer Part Number | G17M0115EW300# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
