Ashcroft 3G-OTH-176438 — Technical Specifications

Name: Ashcroft 3G-OTH-176438 Pressure Transmitter: 0 psi to 500 psi, 4 to 20mA DC, Cable & Wire Leads, 7/16 in Male SAE, IP67 /4X (MPN G17MEK42F2500#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 10x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 2x Range.
Brand: Ashcroft

The ASHCROFT G2 Pressure Transmitter (0 psi to 500 psi) is a pressure transmitter with cable and wire leads, featuring a 4 to 20mA DC output, ±0.5% accuracy, and a nylon housing with IP67 and NEMA 4X ratings. It offers an overpressure of 2x range and a burst pressure of 10x range, with a 7/16 in male SAE process connection.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Type	Cable & Wire Leads, IP67 /4X
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
Male SAE	7/16 in
IP Rating	IP67
NEMA Rating	4X
Overpressure	2x Range
Burst Pressure	10x Range
Housing Material	Nylon
Process Connection Type	SAE
Manufacturer Part Number	G17MEK42F2500#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
