Ashcroft 3G-OTH-176257 — Technical Specifications

Name: Ashcroft 3G-OTH-176257 Pressure Transmitter: 0 psi to 7,500 psi, 4 to 20mA DC, 4-Pin Mini-DIN Hirschmann G Series Connector (MPN G17MEK42M17500#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 5x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 1.5x Range.
Brand: Ashcroft

The ASHCROFT G2 Pressure Transmitter with 4-Pin Mini-DIN Connector (SKU 5DEJ9) measures 0 psi to 7,500 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features an IP67 and NEMA 4X rated nylon housing, overpressure of 1.5x range, and burst pressure of 5x range. The SAE male process connection and Hirschmann G Series connector enable straightforward installation in industrial systems.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Type	4-Pin Mini-DIN Hirschmann G Series Connector
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
IP Rating	IP67
NEMA Rating	4X
Overpressure	1.5x Range
Burst Pressure	5x Range
Housing Material	Nylon
Process Connection Type	SAE
Manufacturer Part Number	G17MEK42M17500#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
