Ashcroft 3G-OTH-176269 — Technical Specifications

Name: Ashcroft 3G-OTH-176269 Pressure Transmitter: 0 psi to 3,000 psi, 4 to 20mA DC, 4-Pin Mini-DIN Hirschmann G Series Connector (MPN G17MEK42M13000#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 5x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 2x Range.
Brand: Ashcroft

The ASHCROFT G2 Pressure Transmitter (0 psi to 3,000 psi) is a pressure transmitter with a 4-Pin Mini-DIN Connector, featuring a 4 to 20mA DC output. It offers ±0.5% accuracy, an IP67 and NEMA 4X rating, and a nylon housing. Overpressure is 2x range, burst pressure is 5x range, and the process connection is SAE male.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Type	4-Pin Mini-DIN Hirschmann G Series Connector
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
IP Rating	IP67
NEMA Rating	4X
Overpressure	2x Range
Burst Pressure	5x Range
Housing Material	Nylon
Process Connection Type	SAE
Manufacturer Part Number	G17MEK42M13000#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
