Ashcroft 3G-OTH-176265 — Technical Specifications

Name: Ashcroft 3G-OTH-176265 Pressure Transmitter: 0 psi to 200 psi, 4 to 20mA DC, 4-Pin Mini-DIN Hirschmann G Series Connector (MPN G17MEK42M1200#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 10x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 2x Range.
Brand: Ashcroft

The ASHCROFT G2 Series Pressure Transmitter (SKU 5DEJ3) is a 0 psi to 200 psi pressure transmitter with a 4-Pin Mini-DIN connector. It features a 4 to 20mA DC output, ±0.5% accuracy, and an IP67 / NEMA 4X rating. The nylon housing includes an SAE male process connection, with overpressure of 2x range and burst pressure of 10x range.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Type	4-Pin Mini-DIN Hirschmann G Series Connector
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
IP Rating	IP67
NEMA Rating	4X
Overpressure	2x Range
Burst Pressure	10x Range
Housing Material	Nylon
Process Connection Type	SAE
Manufacturer Part Number	G17MEK42M1200#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
