Ashcroft 3G-OTH-176225 — Technical Specifications

Name: Ashcroft 3G-OTH-176225 Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC, 4-Pin Mini-DIN Hirschmann G Series Connector (MPN G17M0142M1VAC/30#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 10x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 2x Range.
Brand: Ashcroft

The ASHCROFT G2 Pressure Transmitter with 4-Pin Mini-DIN Connector (SKU 5DEG8) measures -15 psi to 30 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features an IP67 and NEMA 4X rated nylon housing, 2x range overpressure, and 10x range burst pressure with a male NPT process connection.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Type	4-Pin Mini-DIN Hirschmann G Series Connector
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
IP Rating	IP67
NEMA Rating	4X
Overpressure	2x Range
Burst Pressure	10x Range
Pressure Range	-15 psi to 30 psi
Housing Material	Nylon
Process Connection Type	NPT
Manufacturer Part Number	G17M0142M1VAC/30#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
