Ashcroft 3G-OTH-176238 — Technical Specifications
The ASHCROFT G2 Series Pressure Transmitter (SKU 5DEG6) is a 0 psi to 5,000 psi pressure transmitter with a 4-Pin Mini-DIN Hirschmann G Series Connector and a 4 to 20mA DC output. It features an accuracy of ±0.5%, an IP67 and NEMA 4X rating, a nylon housing, and a 1.5x range overpressure with 5x range burst pressure. The process connection is a male NPT type.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Type | 4-Pin Mini-DIN Hirschmann G Series Connector |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | G2 |
| Accuracy | ±0.5% |
| IP Rating | IP67 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| Burst Pressure | 5x Range |
| Housing Material | Nylon |
| Process Connection Type | NPT |
| Manufacturer Part Number | G17M0242M15000# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
