Ashcroft 3G-OTH-176242 — Technical Specifications
The ASHCROFT G2 Series Pressure Transmitter with 4-Pin Mini-DIN Connector (SKU 5DEF7) measures -15 psi to 30 psi with a 4 to 20mA DC output and ±0.5% accuracy. It features an IP67 and NEMA 4X rating, a nylon housing, and a male NPT process connection. Overpressure is 2x range, burst pressure is 10x range, and no NIST-traceable calibration certificate is included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Type | 4-Pin Mini-DIN Hirschmann G Series Connector |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | G2 |
| Accuracy | ±0.5% |
| IP Rating | IP67 |
| NEMA Rating | 4X |
| Overpressure | 2x Range |
| Burst Pressure | 10x Range |
| Pressure Range | -15 psi to 30 psi |
| Housing Material | Nylon |
| Process Connection Type | NPT |
| Manufacturer Part Number | G17M0242M1VAC/30# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
