Ashcroft 3G-OTH-176734 — Technical Specifications
The ASHCROFT G2 Series Pressure Transmitter (SKU 5DEA3) is a 0 psi to 7,500 psi pressure transmitter with a 4-Pin M12 Connector and a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a nylon housing, and a 7/16 in Male SAE process connection. Overpressure capability is 1.5x range, with burst pressure at 5x range.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | G2 |
| Accuracy | ±0.5% |
| Male SAE | 7/16 in |
| IP Rating | IP67 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| M12 Connector | 4-Pin |
| Burst Pressure | 5x Range |
| Housing Material | Nylon |
| Process Connection Type | SAE |
| Manufacturer Part Number | G17MEK42EW7500# |
| Process Connection Gender | Male |
| Calibration Certificate Included | No NIST-Traceable Calibration Certificate Included |
