Ashcroft 3G-OTH-176654 — Technical Specifications

Name: Ashcroft 3G-OTH-176654 Pressure Transmitter: 0 psi to 3,000 psi, 4 to 20mA DC, 4-Pin M12 Connector, 1/8 in Male NPT (MPN G17M0142EW3000#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 5x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 2x Range.
Brand: Ashcroft

The ASHCROFT G2 Series Pressure Transmitter (SKU 5DDZ0) is a 0 psi to 3,000 psi pressure transmitter with a 4-Pin M12 Connector and 1/8 in Male NPT process connection. It features a 4 to 20mA DC output, ±0.5% accuracy, IP67 and NEMA 4X ratings, a nylon housing, overpressure of 2x range, and burst pressure of 5x range.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
Male NPT	1/8 in
IP Rating	IP67
NEMA Rating	4X
Overpressure	2x Range
M12 Connector	4-Pin
Burst Pressure	5x Range
Housing Material	Nylon
Process Connection Type	NPT
Manufacturer Part Number	G17M0142EW3000#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
