Ashcroft 3G-OTH-176647 — Technical Specifications

Name: Ashcroft 3G-OTH-176647 Pressure Transmitter: -15 psi to 30 psi, 4 to 20mA DC, 4-Pin M12 Connector, 1/8 in Male NPT (MPN G17M0142EWVAC/30#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 10x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 2x Range.
Brand: Ashcroft

The ASHCROFT G2 Series Pressure Transmitter with 4-Pin M12 Connector (SKU 5DDY2, MPN G17M0142EWVAC/30#) measures -15 psi to 30 psi with a 4 to 20mA DC output. It features ±0.5% accuracy, an IP67 and NEMA 4X rating, a nylon housing, and a 1/8 in Male NPT process connection. Overpressure is 2x range and burst pressure is 10x range; no NIST-traceable calibration certificate is included.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
Male NPT	1/8 in
IP Rating	IP67
NEMA Rating	4X
Overpressure	2x Range
M12 Connector	4-Pin
Burst Pressure	10x Range
Pressure Range	-15 psi to 30 psi
Housing Material	Nylon
Process Connection Type	NPT
Manufacturer Part Number	G17M0142EWVAC/30#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
