Ashcroft 3G-OTH-176667 — Technical Specifications

Name: Ashcroft 3G-OTH-176667 Pressure Transmitter: 0 psi to 7,500 psi, 4 to 20mA DC, 4-Pin M12 Connector, 1/4 in Male NPT (MPN G17M0242EW7500#). Key specifications — Accuracy: ±0.5%; NEMA Rating: 4X; Burst Pressure: 5x Range; Calibration Certificate Included: No NIST-Traceable Calibration Certificate Included; IP Rating: IP67; Housing Material: Nylon; Output: 4 to 20mA DC; Overpressure: 1.5x Range.
Brand: Ashcroft

The ASHCROFT G2 Pressure Transmitter (SKU 5DDY1) is a 0 psi to 7,500 psi pressure transmitter with a 4-Pin M12 Connector. It features a 4 to 20mA DC output, ±0.5% accuracy, and an IP67 / NEMA 4X rating. The nylon-housed unit has a 1/4 in Male NPT process connection, with overpressure of 1.5x Range and burst pressure of 5x Range.

View Product & Quote

Technical Specifications

Parameter	Value
DC	4 to 20mA
Brand	ASHCROFT
Output	4 to 20mA DC
Series	G2
Accuracy	±0.5%
Male NPT	1/4 in
IP Rating	IP67
NEMA Rating	4X
Overpressure	1.5x Range
M12 Connector	4-Pin
Burst Pressure	5x Range
Housing Material	Nylon
Process Connection Type	NPT
Manufacturer Part Number	G17M0242EW7500#
Process Connection Gender	Male
Calibration Certificate Included	No NIST-Traceable Calibration Certificate Included
