Ashcroft 3G-OTH-176558 — Technical Specifications
The ASHCROFT A4 Series Intrinsically Safe-Rated Transmitter (SKU 5DDK1) is a gauge pressure transmitter with a 0 psi to 60 psi range and a 4 to 20mA DC output. It features a stainless steel housing, an IP65 / NEMA 4X rating, and a Hirschmann® Form A DIN 43650-A electrical connection. The unit offers ±0.50% of Full Scale accuracy, an overpressure of 1.5x Range, a burst pressure of 2x Range, and carries a Class II, Div 1 and 2, Group F, G safety rating. A NIST-Traceable Calibration Certificate is included.
Technical Specifications
| Parameter | Value |
|---|---|
| DC | 4 to 20mA |
| Type | Hirschmann® Form A DIN 43650-A, IP65 /4X, Gauge |
| Brand | ASHCROFT |
| Output | 4 to 20mA DC |
| Series | A4 |
| Accuracy | ±0.50% of Full Scale |
| IP Rating | IP65 |
| NEMA Rating | 4X |
| Overpressure | 1.5x Range |
| Product Type | Intrinsically Safe-Rated Transmitter |
| Safety Rating | Class II, Div 1 and 2, Group F, G |
| Burst Pressure | 2x Range |
| Housing Material | Stainless Steel |
| Intrinsically Safe | Intrinsically Safe |
| Electrical Connection | Hirschmann® Form A DIN 43650-A |
| Pressure Type Measured | Gauge |
| Process Connection Type | NPT |
| Manufacturer Part Number | A4SBF0442D060# |
| NIST Traceable Certificate | NIST-Traceable Calibration Certificate Included |
