Armstrong International 3G-OTH-69797 — Technical Specifications
The Armstrong International Cast Iron C-Pattern Float & Thermostatic Steam Trap (MPN 15B8) is a horizontal-installation steam trap with a stainless steel float. It features a 2-inch FNPT connection, a maximum capacity of 9,000 lb/hr, and a maximum operating pressure of 15 psi at 377°F. This unit is part of the Manufacturer Series B.
Technical Specifications
| Parameter | Value |
|---|---|
| FNPT | 2 in |
| Max. | 15 psi |
| Type | 9,000 lb/hr, C Pattern |
| Brand | ARMSTRONG INTERNATIONAL |
| Float Material | Stainless Steel |
| Manufacturer Series | B |
| Installation Orientation | Horizontal |
| Manufacturer Part Number | 15B8 |
