Approved Vendor 3G-OTH-533998 — Technical Specifications
The APPROVED VENDOR Self Locking Thread Insert (Std Wall, MPN EZ-329-5) is a standard-wall, inch-system insert with a 5/16"-18 internal thread size and a 1/2"-13 external thread size. It features coarse threads, a 27/64 drill bit size, a compatible tap size of 1/2"-13, and external/internal thread fits of 2A and 2B respectively.
Technical Specifications
| Parameter | Value |
|---|---|
| Wall Type | Standard Wall |
| Ext Thrd Sz | 1/2"-13 |
| Int Thrd Sz | 5/16"-18 |
| Thread Type | Coarse |
| Drill Bit Size | 27/64 |
| Compatible Tap Size | 1/2"-13 |
| External Thread Fit | 2A |
| Internal Thread Fit | 2B |
| System Of Measurement | Inch |
| Manufacturer Part Number | EZ-329-5 |
