WEATHERHEAD Compression Tee Fitting: 1/4 in OD x 1/8 in Pipe x 1/4 in OD Size - Flareless Bite-Type Steel Compression Fittings
WEATHERHEADFlareless Bite-Type Steel Compression Fittings

WEATHERHEAD Compression Tee Fitting: 1/4 in OD x 1/8 in Pipe x 1/4 in OD Size

The WEATHERHEAD Compression Tee Fitting is a flareless bite-type steel compression fitting from the 7000 Series Ermeto, designed for 1/4 in OD tubing with a 1/8 in pipe thread size (1/8"-27). This OEM component (MPN…

SKU 3G-OTH-470208

Brand
WEATHERHEAD
Item
Compression Tee Fitting: 1/4 in OD x 1/8 in Pipe x 1/4 in OD Size
Category
Flareless Bite-Type Steel Compression Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

WEATHERHEAD
Manufacturer Part Number
7755X04X02X04
Series
7000 Series Ermeto
OD Size
1/4 in
Thread Size
1/8"-27
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

WEATHERHEAD Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The WEATHERHEAD Compression Tee Fitting is a flareless bite-type steel compression fitting from the 7000 Series Ermeto, designed for 1/4 in OD tubing with a 1/8 in pipe thread size (1/8"-27). This OEM component (MPN 7755X04X02X04) supports three-way connections in industrial fluid systems.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a WEATHERHEAD Compression Tee Fitting used for?

The WEATHERHEAD Compression Tee Fitting (MPN 7755X04X02X04) creates a three-way branch in industrial fluid systems using 1/4 in OD tubing and 1/8 in pipe threads. It is a flareless bite-type steel compression fitting from the 7000 Series Ermeto, commonly applied in hydraulic, pneumatic, and lubrication circuits.

What are the specifications of the WEATHERHEAD 7755X04X02X04?

This WEATHERHEAD Compression Tee Fitting is a 7000 Series Ermeto flareless bite-type steel fitting. It accommodates 1/4 in OD tubing on two ports and a 1/8 in pipe thread (1/8"-27) on the third port. The OEM part number is 7755X04X02X04, designed for reliable three-way connections.

Where to buy WEATHERHEAD Compression Tee Fittings worldwide?

3G Electric supplies the WEATHERHEAD 7000 Series Ermeto Compression Tee Fitting (MPN 7755X04X02X04) to customers worldwide. We handle full logistics, customs clearance, and delivery for global orders. Contact our team to source this OEM component for your industrial fluid system needs.

How to install a WEATHERHEAD flareless bite-type compression fitting?

To install a WEATHERHEAD 7000 Series Ermeto fitting, cut tubing squarely, deburr, and slide the nut and ferrule onto the tube. Insert the tube into the fitting body until it seats, then tighten the nut to the manufacturer's recommended torque. Avoid overtightening to prevent tube collapse or ferrule damage.

Used in

Common applications for WEATHERHEAD
Mobile hydraulic systems — Weatherhead hydraulic flange fittings (e.g., 12Z-G42) for hose assemblies in excavators and loaders
Pneumatic tool lines — Weatherhead quick-connect couplings (e.g., 430) for air supply connections in manufacturing plants
Industrial machinery — Weatherhead 45° elbow flange fittings (e.g., 20Z-G54) for hydraulic power units
Fluid transfer systems — Weatherhead straight flange fittings (e.g., 16Z-G20) for high-pressure oil lines
Maintenance and repair — Weatherhead quick-connect bodies (e.g., 580) for replacing worn couplings on pneumatic tools
Hydraulic press applications — Weatherhead 90° elbow flange fittings (e.g., 24Z-G84) for compact hose routing in tight spaces

WEATHERHEAD Products

3G Electric supplies WEATHERHEAD flareless bite-type steel compression fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
