WEATHERHEAD Compression Fitting Elbow: 1 in OD x 1 in OD Size
The WEATHERHEAD Compression Fitting Elbow is a flareless bite-type steel compression fitting from the Ermeto Flareless series, sized 1 in OD x 1 in OD with a thread size of 1 5/16-12 x 1-5/16-12 (MPN 7505X16X16). 3G…
SKU 3G-OTH-469757
Need installation or engineering help?
Ask a question
Product Description
The WEATHERHEAD Compression Fitting Elbow is a flareless bite-type steel compression fitting from the Ermeto Flareless series, sized 1 in OD x 1 in OD with a thread size of 1 5/16-12 x 1-5/16-12 (MPN 7505X16X16). 3G Electric interprets this demand and sources the genuine OEM part, backed by specialist expertise in fluid-power components across our 14 industrial departments.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is a WEATHERHEAD compression fitting elbow used for?
The WEATHERHEAD compression fitting elbow connects two 1 in OD tubes at a 90° angle in hydraulic or pneumatic systems. It uses a flareless bite-type design to grip tubing without flaring, ideal for high-pressure fluid power applications in industrial machinery and mobile equipment.
What are the specifications of the WEATHERHEAD 7505X16X16?
The WEATHERHEAD 7505X16X16 is a flareless bite-type steel compression elbow from the Ermeto Flareless series. It has a 1 in OD x 1 in OD size with a thread size of 1 5/16-12 x 1-5/16-12. The manufacturer part number is 7505X16X16.
Where to buy WEATHERHEAD compression fittings worldwide?
3G Electric supplies genuine WEATHERHEAD compression fittings worldwide. We interpret your demand, source the OEM part, and handle logistics, customs, and delivery to your site globally. Contact us for availability and lead time on the 7505X16X16 or other Ermeto Flareless fittings.
How to install a WEATHERHEAD flareless bite-type compression fitting?
To install a WEATHERHEAD flareless bite-type fitting, cut tubing square, deburr, and insert fully into the fitting. Tighten the nut until the ferrule bites into the tube, then follow the manufacturer's torque specification. Avoid over-tightening to prevent tube collapse. Always use genuine WEATHERHEAD parts for reliable sealing.
Used in
Common applications for WEATHERHEADWEATHERHEAD Products
3G Electric supplies WEATHERHEAD flareless bite-type steel compression fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
