WEATHERHEAD Compression Fitting Elbow: 1/4 in OD x 1/8 in Pipe Size
The WEATHERHEAD Compression Fitting Elbow (MPN 7405X04X02) is a flareless bite-type steel compression fitting from the Ermeto Flareless series, designed for 1/4 in OD tubing with a 1/8 in pipe size connection. It…
SKU 3G-OTH-470242
Need installation or engineering help?
Ask a question
Product Description
The WEATHERHEAD Compression Fitting Elbow (MPN 7405X04X02) is a flareless bite-type steel compression fitting from the Ermeto Flareless series, designed for 1/4 in OD tubing with a 1/8 in pipe size connection. It features a 7/16-20 x 1/8-27 thread size, providing a reliable, leak-resistant joint in hydraulic and pneumatic systems.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is a WEATHERHEAD Ermeto Flareless compression fitting elbow used for?
This WEATHERHEAD compression fitting elbow (MPN 7405X04X02) creates leak-resistant joints in hydraulic and pneumatic systems. It connects 1/4 in OD tubing to a 1/8 in pipe port, commonly used in industrial fluid power, instrumentation, and machine tool applications where reliable sealing under pressure is required.
What are the specifications of the WEATHERHEAD 7405X04X02 compression fitting?
The WEATHERHEAD 7405X04X02 is a flareless bite-type steel compression elbow from the Ermeto Flareless series. It has a 7/16-20 x 1/8-27 thread size, designed for 1/4 in OD tubing with a 1/8 in pipe size connection. The steel construction provides durability in demanding environments.
Where to buy WEATHERHEAD compression fittings worldwide?
3G Electric supplies WEATHERHEAD compression fittings like the Ermeto Flareless elbow (7405X04X02) to customers worldwide. We handle full logistics, customs clearance, and delivery for global orders. Contact our team to source this part for your hydraulic or pneumatic system requirements.
How to install a WEATHERHEAD flareless bite-type compression fitting?
To install a WEATHERHEAD Ermeto Flareless fitting, insert the tubing fully into the fitting until it bottoms out, then tighten the nut to the manufacturer's recommended torque. The bite ring grips the tube without flaring, creating a leak-resistant seal. Always follow standard hydraulic fitting installation practices for best results.
