WEATHERHEAD Compression Fitting Elbow: 1/4 in OD x 1/8 in Pipe Size
The WEATHERHEAD Compression Fitting Elbow (MPN 7355X04X02) is a flareless bite-type steel compression fitting from the Ermeto Flareless series, designed for 1/4 in OD tube to 1/8 in pipe size connections with 7/16-20…
SKU 3G-OTH-470389
Need installation or engineering help?
Ask a question
Product Description
The WEATHERHEAD Compression Fitting Elbow (MPN 7355X04X02) is a flareless bite-type steel compression fitting from the Ermeto Flareless series, designed for 1/4 in OD tube to 1/8 in pipe size connections with 7/16-20 x 1/8-27 thread sizes.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is a WEATHERHEAD Ermeto flareless compression fitting elbow used for?
This WEATHERHEAD Ermeto flareless compression fitting elbow connects 1/4 in OD tube to 1/8 in pipe in hydraulic and pneumatic systems. It provides a leak-tight, bite-type seal without flaring, ideal for high-pressure industrial applications across machining, power transmission, and instrumentation.
What are the specifications of the WEATHERHEAD 7355X04X02 compression fitting?
The WEATHERHEAD 7355X04X02 is a flareless bite-type steel compression elbow from the Ermeto Flareless series. It has a 7/16-20 x 1/8-27 thread size, connecting 1/4 in OD tube to 1/8 in pipe size. It is designed for reliable, vibration-resistant connections in fluid power systems.
Where to buy WEATHERHEAD compression fittings worldwide?
3G Electric supplies WEATHERHEAD compression fittings like the Ermeto Flareless elbow (MPN 7355X04X02) to customers worldwide. We handle full logistics, customs clearance, and delivery, ensuring you get the right industrial fitting for your application, no matter your location.
How to install a WEATHERHEAD flareless bite-type compression fitting?
To install a WEATHERHEAD Ermeto flareless fitting, cut the tube square, deburr, and insert it fully into the fitting. Tighten the nut until the ferrule bites into the tube, then follow the manufacturer's recommended torque. This creates a permanent, leak-free seal without flaring the tube end.
Used in
Common applications for WEATHERHEADWEATHERHEAD Products
3G Electric supplies WEATHERHEAD flareless bite-type steel compression fittings. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
