TEMPCO Ring Thermocouple: 32°F to 2,300°F /0°C to 1,260°C, Type K - Thermocouples for Surface Applications
TEMPCOThermocouples for Surface Applications

TEMPCO Ring Thermocouple: 32°F to 2,300°F /0°C to 1,260°C, Type K

The TEMPCO Ring Thermocouple is a Type K thermocouple for surface applications, designed to measure temperatures from 32°F to 2,300°F (0°C to 1,260°C). It features a 12 ft fiberglass cable with stainless steel braid…

SKU 3G-OTH-182355

Brand
TEMPCO
Item
Ring Thermocouple: 32°F to 2,300°F /0°C to 1,260°C, Type K
Category
Thermocouples for Surface Applications
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TEMPCO
Manufacturer Part Number
TRW00114
Type
Type K, For Solids/Surfaces Media Type
Accuracy
±2.2 °C or ±0.75 %, Whichever is Greater
Cable Length
12 ft
Cable Material
Fiberglass with Stainless Steel Braid
Maximum Wire Gauge
0.25 mm
Process Mounting Connection
Bolt
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TEMPCO Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TEMPCO Ring Thermocouple is a Type K thermocouple for surface applications, designed to measure temperatures from 32°F to 2,300°F (0°C to 1,260°C). It features a 12 ft fiberglass cable with stainless steel braid, a bolt mounting connection, and an accuracy of ±2.2 °C or ±0.75%, whichever is greater. The maximum wire gauge is 0.25 mm.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the TEMPCO Ring Thermocouple used for?

The TEMPCO Ring Thermocouple is designed for surface temperature measurement on solids and surfaces. It is commonly used in industrial process heating, ovens, kilns, and machinery where bolt-mounting is required. Its Type K thermocouple element covers a range of 32°F to 2,300°F (0°C to 1,260°C).

What are the specifications of the TEMPCO Ring Thermocouple?

This TEMPCO Type K thermocouple has a 12 ft fiberglass cable with stainless steel braid, accuracy of ±2.2 °C or ±0.75% (whichever is greater), and a bolt mounting connection. Maximum wire gauge is 0.25 mm. The MPN is TRW00114. It measures from 32°F to 2,300°F (0°C to 1,260°C).

Where to buy the TEMPCO Ring Thermocouple worldwide?

3G Electric supplies the TEMPCO Ring Thermocouple (MPN TRW00114) to customers worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time. We source and deliver this thermocouple for surface applications.

How to install the TEMPCO Ring Thermocouple?

Install the TEMPCO Ring Thermocouple by bolting the ring terminal directly to the solid or surface being measured. Ensure clean, flat contact for accurate readings. Route the 12 ft fiberglass cable away from sharp edges and high-moisture areas. Follow standard thermocouple wiring practices for Type K connections.
