TELEMECANIQUE SENSORS Cordset: M12 Male Straight X M12 Female Straight, 5 Pins, Black, PUR, 5 m Cable Lg - Double-Ended Cordsets with PUR Jacket for Twisting Applications
TELEMECANIQUE SENSORSDouble-Ended Cordsets with PUR Jacket for Twisting Applications

TELEMECANIQUE SENSORS Cordset: M12 Male Straight X M12 Female Straight, 5 Pins, Black, PUR, 5 m Cable Lg

The TELEMECANIQUE SENSORS Cordset (SKU 19MJ48, MPN XZCRA151164D5) is a double-ended cordset with a PUR jacket for twisting applications. It features an M12 male straight connector on one end and an M12 female…

SKU 3G-OTH-50567

Brand
TELEMECANIQUE SENSORS
Item
Cordset: M12 Male Straight X M12 Female Straight, 5 Pins, Black, PUR, 5 m Cable Lg
Category
Double-Ended Cordsets with PUR Jacket for Twisting Applications
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

TELEMECANIQUE SENSORS
Manufacturer Part Number
XZCRA151164D5
Type
Black, PUR
Pins
5
Cable Lg
5 m
IP Rating
IP69K
Wire Size
22 AWG
End 1 Gender
Male
End 2 Gender
Female
Cable Jacket Color
Black
Cable Jacket Material
PUR
End 1 Connection Type
M12
End 2 Connection Type
M12
End 1 Mounting Orientation
Straight
End 2 Mounting Orientation
Straight
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

TELEMECANIQUE SENSORS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The TELEMECANIQUE SENSORS Cordset (SKU 19MJ48, MPN XZCRA151164D5) is a double-ended cordset with a PUR jacket for twisting applications. It features an M12 male straight connector on one end and an M12 female straight connector on the other, with 5 pins, 22 AWG wire size, and a 5 m cable length. The black PUR jacket provides an IP69K rating.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the TELEMECANIQUE SENSORS XZCRA151164D5 cordset used for?

This double-ended cordset with M12 male-to-female straight connectors and a PUR jacket is used for sensor and actuator connections in industrial automation, especially in twisting or flexing cable applications. Its IP69K rating suits washdown environments in food, beverage, and packaging industries.

What are the specifications of the TELEMECANIQUE SENSORS XZCRA151164D5 cordset?

The cordset has 5 pins, 22 AWG wire size, 5 m cable length, black PUR jacket, and M12 male straight to M12 female straight connectors. It carries an IP69K rating for high-pressure, high-temperature washdown. The manufacturer part number is XZCRA151164D5.

Where to buy TELEMECANIQUE SENSORS XZCRA151164D5 cordset worldwide?

3G Electric supplies the TELEMECANIQUE SENSORS XZCRA151164D5 cordset worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on this double-ended M12 cordset.

How to install a TELEMECANIQUE SENSORS M12 cordset?

Align the keyway of the M12 male connector with the female receptacle, push straight in, and tighten the coupling nut by hand until snug. Do not overtighten. For the PUR jacket, avoid sharp bends below the minimum bend radius specified by the manufacturer to maintain IP69K sealing.
