STANDARD XCHANGE Gasketed Plate Heat Exchanger: 3,909,800 BtuH Water / 697,700 BtuH Oil, 86 gpm - Plate & Frame Heat Exchangers
STANDARD XCHANGEPlate & Frame Heat Exchangers

STANDARD XCHANGE Gasketed Plate Heat Exchanger: 3,909,800 BtuH Water / 697,700 BtuH Oil, 86 gpm

The STANDARD XCHANGE Gasketed Plate Heat Exchanger (MPN P14-40-TL) is a plate and frame unit rated at 3,909,800 BtuH for water and 697,700 BtuH for oil, with a flow capacity of 86 gpm and a surface area of 61.35 sq…

SKU 3G-OTH-62464

Brand
STANDARD XCHANGE
Item
Gasketed Plate Heat Exchanger: 3,909,800 BtuH Water / 697,700 BtuH Oil, 86 gpm
Category
Plate & Frame Heat Exchangers
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

STANDARD XCHANGE
Manufacturer Part Number
P14-40-TL
Type
86 gpm, 61.35 sq ft
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

STANDARD XCHANGE Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The STANDARD XCHANGE Gasketed Plate Heat Exchanger (MPN P14-40-TL) is a plate and frame unit rated at 3,909,800 BtuH for water and 697,700 BtuH for oil, with a flow capacity of 86 gpm and a surface area of 61.35 sq ft. 3G Electric interprets this demand and sources the exact OEM part, backed by specialist expertise in pumps and controls to support your thermal management system.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the STANDARD XCHANGE P14-40-TL gasketed plate heat exchanger used for?

The STANDARD XCHANGE P14-40-TL is a gasketed plate heat exchanger designed for liquid-to-liquid heat transfer in industrial processes. Typical applications include water heating, oil cooling, and thermal management in HVAC, chemical processing, and power generation systems where high efficiency and compact size are required.

What are the specifications of the STANDARD XCHANGE P14-40-TL heat exchanger?

The P14-40-TL has a heat transfer capacity of 3,909,800 BtuH with water and 697,700 BtuH with oil. It handles a flow rate of 86 gpm and provides 61.35 sq ft of heat transfer surface area. The unit is a gasketed plate-and-frame design from STANDARD XCHANGE, MPN P14-40-TL.

Where to buy the STANDARD XCHANGE P14-40-TL heat exchanger worldwide?

3G Electric supplies the STANDARD XCHANGE P14-40-TL gasketed plate heat exchanger to customers worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install a gasketed plate heat exchanger like the P14-40-TL?

Install the heat exchanger on a level foundation with adequate clearance for plate removal. Connect piping to the correct ports per the flow diagram, ensuring gaskets are properly seated. Tighten the frame bolts evenly to the torque specified by STANDARD XCHANGE. Pressure test before full operation.

Used in

Common applications for STANDARD XCHANGE
HVAC systems — STANDARD XCHANGE SX2000 series shell-and-tube heat exchangers for building cooling loops
Process cooling — STANDARD XCHANGE SN503008 series brass-shell units for industrial water cooling at 105 gpm
Maintenance and retrofit — STANDARD XCHANGE 810RG7 Nitrile HT gaskets for plate heat exchanger rebuilds
Hydronic heating — STANDARD XCHANGE copper-tube heat exchangers for boiler-to-water heat transfer
Oil cooling — STANDARD XCHANGE shell-and-tube units with carbon steel shells for lubricating oil systems

STANDARD XCHANGE Products

3G Electric supplies STANDARD XCHANGE plate & frame heat exchangers. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
