SNAP-TITEH Series Hydraulic Quick-Connect Coupling Bodies

SNAP-TITE Hydraulic Quick Connect Hose Coupling: 1 in, 316 Stainless Steel

SKU 3G-OTH-462719

Brand

SNAP-TITE

Item

Hydraulic Quick Connect Hose Coupling: 1 in, 316 Stainless Steel

Technical Specifications

SNAP-TITE

Manufacturer Part Number

SVHC16-16M

Thread Size

1"-11-1/2

Seal Material

Nitrile

Stainless Steel

316

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

SNAP-TITE Products

3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SNAP-TITE H Series Hydraulic Quick-Connect Coupling Body (SKU 20LG65, MPN SVHC16-16M) is a 1-inch coupling with 1"-11-1/2 thread size, constructed from 316 stainless steel with a nitrile seal. 3G Electric interprets your demand for this genuine industrial component, sourcing it across our 14 departments and supplying it with specialist support in pumps and controls.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a SNAP-TITE H Series hydraulic quick-connect coupling used for?

The SNAP-TITE H Series coupling body is used for quick, leak-free connection and disconnection of hydraulic lines in industrial fluid power systems. It is commonly applied in mobile equipment, machine tools, and oilfield hydraulics where 316 stainless steel resists corrosion and nitrile seals handle petroleum-based fluids.

What are the specifications of the SNAP-TITE SVHC16-16M coupling?

The SNAP-TITE SVHC16-16M is a 1-inch coupling body with 1"-11-1/2 thread size, made from 316 stainless steel with a nitrile seal. It is part of the H Series quick-connect line, designed for high-flow hydraulic applications. 3G Electric supplies this genuine SNAP-TITE component globally.

Where to buy SNAP-TITE hydraulic couplings in worldwide?

3G Electric supplies SNAP-TITE hydraulic couplings worldwide. We interpret your demand, source the genuine component, and handle full logistics and customs clearance for delivery to your site. Contact us for availability and lead time on the SVHC16-16M or other SNAP-TITE H Series parts.

How to select the right SNAP-TITE quick-connect coupling for my system?

Select a SNAP-TITE coupling by matching thread size, seal material, and pressure rating to your hydraulic system. For the SVHC16-16M, confirm your port has 1"-11-1/2 threads and that nitrile seals are compatible with your fluid. 3G Electric provides specialist support in pumps and controls to help you choose.

Used in

Common applications for SNAP-TITE

Hydraulic tool maintenance — SNAP-TITE IH Series couplings (e.g., VIHC6-6F) for quick hose connections in hydraulic wrenches and crimpers.

Agricultural equipment — SNAP-TITE IH Series couplings (e.g., VIHC4-4M) for hydraulic lines on tractors and harvesters.

Construction machinery — SNAP-TITE IH Series couplings (e.g., VIHC8-8F) for hydraulic circuits on excavators and loaders.

Industrial fluid power systems — SNAP-TITE IH Series couplings (e.g., VIHC12-12F) for connecting hydraulic power units to actuators.

Mobile hydraulic systems — SNAP-TITE IH Series couplings (e.g., VIHC6-6M) for quick disconnects on forklifts and aerial lifts.
