SMC High Purity Tube Fitting: 1/4 in Pipe x 3/8 in OD Size, NPT x Compression - PFA Compression Tube Fittings
SMCPFA Compression Tube Fittings

SMC High Purity Tube Fitting: 1/4 in Pipe x 3/8 in OD Size, NPT x Compression

The SMC High Purity Tube Fitting (MPN LQ3L3B-MN) is a PFA compression tube fitting with a 1/4 in NPT pipe x 3/8 in OD size connection. Part of the LQ3 series, it meets RoHS_6 and RoHS_10 standards.

SKU 3G-OTH-474406

Brand
SMC
Item
High Purity Tube Fitting: 1/4 in Pipe x 3/8 in OD Size, NPT x Compression
Category
PFA Compression Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
LQ3L3B-MN
Series
LQ3
Type
NPT x Compression, PFA
Standards
RoHS_6, RoHS_10
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC High Purity Tube Fitting (MPN LQ3L3B-MN) is a PFA compression tube fitting with a 1/4 in NPT pipe x 3/8 in OD size connection. Part of the LQ3 series, it meets RoHS_6 and RoHS_10 standards.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the SMC LQ3L3B-MN high purity tube fitting used for?

The SMC LQ3L3B-MN is a PFA compression tube fitting used in high-purity fluid systems, such as semiconductor, pharmaceutical, and chemical processing. It connects 1/4 in NPT pipe to 3/8 in OD tubing, ensuring leak-free, corrosion-resistant performance in critical applications.

What are the specifications of the SMC LQ3L3B-MN fitting?

The SMC LQ3L3B-MN is a PFA compression fitting from the LQ3 series. It has a 1/4 in NPT male pipe x 3/8 in OD tube connection, NPT x compression type, and meets RoHS_6 and RoHS_10 standards. The manufacturer part number is LQ3L3B-MN.

Where to buy the SMC LQ3L3B-MN fitting worldwide?

3G Electric supplies the SMC LQ3L3B-MN high purity tube fitting worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this PFA compression fitting to your facility, regardless of location.

How to install the SMC LQ3L3B-MN PFA compression fitting?

To install the SMC LQ3L3B-MN, ensure tubing is cut square and deburred. Insert the tube fully into the fitting, then hand-tighten the nut. Use a wrench for final tightening per manufacturer torque specs. Avoid over-tightening to prevent PFA creep. Always verify leak-free operation.
