SMC High Purity Tube Fitting: 1/4 in Pipe x 1/4 in OD Size, NPT x Compression - PFA Compression Tube Fittings
SMCPFA Compression Tube Fittings

SMC High Purity Tube Fitting: 1/4 in Pipe x 1/4 in OD Size, NPT x Compression

The SMC High Purity Tube Fitting is a PFA compression tube fitting with a 1/4 in NPT pipe x 1/4 in OD size, part of the LQ3 series. This NPT x Compression, PFA type fitting (MPN LQ3L2B-MN) complies with RoHS_6 and…

SKU 3G-OTH-474274

Brand
SMC
Item
High Purity Tube Fitting: 1/4 in Pipe x 1/4 in OD Size, NPT x Compression
Category
PFA Compression Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
LQ3L2B-MN
Series
LQ3
Type
NPT x Compression, PFA
Standards
RoHS_6, RoHS_10
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC High Purity Tube Fitting is a PFA compression tube fitting with a 1/4 in NPT pipe x 1/4 in OD size, part of the LQ3 series. This NPT x Compression, PFA type fitting (MPN LQ3L2B-MN) complies with RoHS_6 and RoHS_10 standards.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the SMC LQ3L2B-MN high purity tube fitting used for?

The SMC LQ3L2B-MN is a PFA compression tube fitting used in high-purity fluid handling systems, such as semiconductor manufacturing, chemical processing, and pharmaceutical applications. It connects 1/4 in NPT pipe to 1/4 in OD tubing, ensuring leak-free, corrosion-resistant connections in critical environments.

What are the specifications of the SMC LQ3L2B-MN fitting?

The SMC LQ3L2B-MN is a PFA compression tube fitting from the LQ3 series. It has a 1/4 in NPT pipe x 1/4 in OD size, NPT x Compression connection type, and complies with RoHS_6 and RoHS_10 standards. The manufacturer part number is LQ3L2B-MN.

Where to buy the SMC LQ3L2B-MN high purity tube fitting worldwide?

3G Electric supplies the SMC LQ3L2B-MN high purity tube fitting worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your location. Contact us for pricing and lead time on this PFA compression fitting.

How to install the SMC LQ3L2B-MN PFA compression fitting?

To install the SMC LQ3L2B-MN, ensure tubing is cut square and deburred. Insert tubing fully into the fitting, then hand-tighten the nut. Use a wrench to tighten an additional 1/4 to 1/2 turn for PFA fittings. Avoid over-tightening to prevent damage. Always follow SMC's installation guidelines for high-purity applications.
