PALMGREN Butt and Fillet Weld Gauge: Inch
The PALMGREN Butt and Fillet Weld Gauge (MPN 9655501) is an automatic weld size gauge designed for measuring fillet size range. It displays measurements in inches with 1/32 in unit of measure increments.
SKU 3G-OTH-360313
Need installation or engineering help?
Ask a question
Product Description
The PALMGREN Butt and Fillet Weld Gauge (MPN 9655501) is an automatic weld size gauge designed for measuring fillet size range. It displays measurements in inches with 1/32 in unit of measure increments.
Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.
Frequently Asked Questions
What is the PALMGREN Butt and Fillet Weld Gauge used for?
The PALMGREN Butt and Fillet Weld Gauge is used to measure fillet weld sizes in inch units. It is commonly applied in welding inspection, quality control, and fabrication to verify weld leg dimensions meet specifications. This automatic gauge simplifies measurement of fillet size range for structural and industrial welding projects.
What are the specifications of the PALMGREN Butt and Fillet Weld Gauge?
The PALMGREN Butt and Fillet Weld Gauge (MPN 9655501) measures fillet size range with display units in inches and 1/32 in increments. It is an automatic weld size gauge from PALMGREN, designed for precise fillet weld measurement. No other measurement functions or ranges are specified by the manufacturer.
Where to buy the PALMGREN Butt and Fillet Weld Gauge worldwide?
You can source the PALMGREN Butt and Fillet Weld Gauge through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact 3G Electric for availability and lead time on this PALMGREN weld gauge.
How to use the PALMGREN Butt and Fillet Weld Gauge?
To use the PALMGREN Butt and Fillet Weld Gauge, place the gauge against the weld joint so the sliding arm contacts the weld face. Read the fillet size directly from the inch scale in 1/32 in increments. Ensure the gauge is clean and perpendicular to the weld for accurate measurement of fillet size range.
Used in
Common applications for PALMGRENPALMGREN Products
3G Electric supplies PALMGREN automatic weld size gauges. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
