LEGRIS Metal Pipe Straight: 180° Return, 1/8 in x 1/4 in, Nickel-Plated Brass - Threaded Medium-Pressure Pipe Fittings
LEGRISThreaded Medium-Pressure Pipe Fittings

LEGRIS Metal Pipe Straight: 180° Return, 1/8 in x 1/4 in, Nickel-Plated Brass

The LEGRIS Metal Pipe Straight: 180° Return is a threaded medium-pressure pipe fitting, type 1/8 in x 1/4 in, constructed of nickel-plated brass with a maximum operating pressure of 870 psi and a length of 49/64 in…

SKU 3G-OTH-464331

Brand
LEGRIS
Item
Metal Pipe Straight: 180° Return, 1/8 in x 1/4 in, Nickel-Plated Brass
Category
Threaded Medium-Pressure Pipe Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
0902 10 13
Type
1/8 in x 1/4 in, Nickel-Plated Brass, 870 psi
Lg
49/64 in
Maximum Operating Pressure
870 psi
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Metal Pipe Straight: 180° Return is a threaded medium-pressure pipe fitting, type 1/8 in x 1/4 in, constructed of nickel-plated brass with a maximum operating pressure of 870 psi and a length of 49/64 in (MPN 0902 10 13).

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the LEGRIS 0902 10 13 metal pipe straight used for?

The LEGRIS 0902 10 13 is a 180° return pipe fitting used to reverse flow direction in medium-pressure pneumatic or fluid systems. It connects 1/8 in and 1/4 in lines, common in industrial automation, packaging, and material handling applications where space is tight.

What are the specifications of the LEGRIS 0902 10 13?

The LEGRIS 0902 10 13 is a nickel-plated brass straight fitting with a 180° return, 1/8 in x 1/4 in connection, maximum operating pressure of 870 psi, and overall length of 49/64 in. It is a threaded medium-pressure pipe fitting from LEGRIS.

Where to buy the LEGRIS 0902 10 13 worldwide?

3G Electric supplies the LEGRIS 0902 10 13 worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this nickel-plated brass 180° return fitting.

How to install a LEGRIS 180° return pipe fitting?

Install the LEGRIS 0902 10 13 by applying thread sealant to male threads and hand-tightening into matching ports. Use a wrench on the hex flats only—avoid overtightening to prevent damage to the nickel-plated brass. Verify pressure rating (870 psi) matches system requirements before use.

Used in

Common applications for LEGRIS
Pneumatic actuator speed control — LEGRIS miniature flow control valve 7665 04 10 for meter-out regulation on 4 mm tubing
Compressed air isolation for maintenance — LEGRIS lockout valve 7886 11 11 for 1/8 in NPT systems
Fluid shutoff in water or oil lines — LEGRIS brass ball valve 0492 07 17 with 3/8 in FNPT connections
Push-to-connect air distribution — LEGRIS nylon ball valve 7915 56 11 for 1/4 in tubing with male NPT adapter
Safety lockout on BSPP pneumatic circuits — LEGRIS lockout valve 7880 10 17 for 3/8 in BSPP systems
Compact on/off control in tight spaces — LEGRIS nylon ball valve 7913 56 00 with push-to-connect ports for 1/4 in tubing
