LEGRIS Push-Fit Union Fitting: 5/32 in OD x 5/32 in OD Size - Nickel-Plated Brass Tube Fittings
LEGRISNickel-Plated Brass Tube Fittings

LEGRIS Push-Fit Union Fitting: 5/32 in OD x 5/32 in OD Size

The LEGRIS Push-Fit Union Fitting (MPN 3616 04 00) is a nickel-plated brass tube fitting with a 5/32 in OD x 5/32 in OD size and a Push-to-Connect x Push-to-Connect type. This OEM component is designed for…

SKU 3G-OTH-483081

Brand
LEGRIS
Item
Push-Fit Union Fitting: 5/32 in OD x 5/32 in OD Size
Category
Nickel-Plated Brass Tube Fittings
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

LEGRIS
Manufacturer Part Number
3616 04 00
Type
Push-to-Connect x Push-to-Connect
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

LEGRIS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The LEGRIS Push-Fit Union Fitting (MPN 3616 04 00) is a nickel-plated brass tube fitting with a 5/32 in OD x 5/32 in OD size and a Push-to-Connect x Push-to-Connect type. This OEM component is designed for straightforward installation in pneumatic or fluid systems requiring a union connection.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a LEGRIS Push-Fit Union Fitting used for?

A LEGRIS Push-Fit Union Fitting connects two 5/32 in OD tubes in pneumatic or fluid systems. Its push-to-connect design enables tool-free installation, making it ideal for maintenance and repair applications in industrial automation, packaging, and material handling equipment.

What are the specifications of the LEGRIS 3616 04 00?

The LEGRIS 3616 04 00 is a nickel-plated brass push-fit union fitting with a 5/32 in OD x 5/32 in OD size. It features push-to-connect x push-to-connect ends for quick, secure tube connections in pneumatic or fluid systems. The OEM part number is 3616 04 00.

Where to buy LEGRIS push-fit fittings worldwide?

3G Electric supplies LEGRIS push-fit fittings like the 3616 04 00 to customers worldwide. We handle full logistics, customs clearance, and delivery to your site. Contact us for a quote on this nickel-plated brass union fitting for your pneumatic or fluid system needs.

How to install a LEGRIS push-to-connect union fitting?

To install a LEGRIS push-fit union fitting, cut the tube square, deburr the end, and push it firmly into the fitting until it stops. The collet grips the tube automatically. For removal, press the release collar and pull the tube out. Ensure the system is depressurized before installation.

Used in

Common applications for LEGRIS
Pneumatic actuator speed control — LEGRIS miniature flow control valve 7665 04 10 for meter-out regulation on 4 mm tubing
Compressed air isolation for maintenance — LEGRIS lockout valve 7886 11 11 for 1/8 in NPT systems
Fluid shutoff in water or oil lines — LEGRIS brass ball valve 0492 07 17 with 3/8 in FNPT connections
Push-to-connect air distribution — LEGRIS nylon ball valve 7915 56 11 for 1/4 in tubing with male NPT adapter
Safety lockout on BSPP pneumatic circuits — LEGRIS lockout valve 7880 10 17 for 3/8 in BSPP systems
Compact on/off control in tight spaces — LEGRIS nylon ball valve 7913 56 00 with push-to-connect ports for 1/4 in tubing
