JW WINCOFully Threaded T-Slot Nuts

JW WINCO T-Slot Nuts: Stainless Steel, For 10 mm T-Slot, M8 Thread

SKU 3G-OTH-231341

Brand

JW WINCO

Item

T-Slot Nuts: Stainless Steel, For 10 mm T-Slot, M8 Thread

Technical Specifications

JW WINCO

Manufacturer Part Number

8NGD2

View Full Spec Sheet

Technical Documents

No technical documents available for this product.

Request documentation →

Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.

Talk to an engineer

Ask a question

JW WINCO Products

3G Electric (S) Pte. Ltd. — Singapore

Frequently Asked Questions

What is a JW WINCO T-Slot Nut used for?

A JW WINCO T-Slot Nut is used to secure components in T-slot aluminum framing systems. It slides into the T-slot channel and provides a threaded anchor point for bolts, enabling quick assembly of machine guards, workstations, and industrial structures.

What are the specifications of the JW WINCO T-Slot Nut 8NGD2?

The JW WINCO T-Slot Nut 8NGD2 is made of stainless steel, fits a 10 mm T-slot, has an M8 thread, and is 15 mm wide. It is a fully threaded nut designed for secure fastening in modular framing systems.

Where to buy JW WINCO T-Slot Nuts worldwide?

You can source JW WINCO T-Slot Nuts worldwide through 3G Electric. We handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time on the 8NGD2 model.

How to install a JW WINCO T-Slot Nut?

To install a JW WINCO T-Slot Nut, slide it into the open end of the T-slot channel, position it at the desired location, and tighten the bolt into the M8 thread. Ensure the nut is fully seated before applying torque to avoid damage.

Used in

Common applications for JW WINCO

Machinery assembly — JW WINCO self-locking bearing locknuts (e.g., 1804.1-M50X1.5) for securing bearings on shafts in gearboxes and conveyors.

Fixture building — JW WINCO horizontal U-latch toggle clamps (e.g., 851.3-700-T6) for quick clamping in welding jigs and assembly fixtures.

Material handling — JW WINCO quick-release hoist rings (e.g., 1135-M12-17-ST) for lifting heavy components in manufacturing cells.

Shaft positioning — JW WINCO one-piece shaft collars (e.g., 5WG46/A) for retaining bearings or acting as stops on linear motion systems.

Linkage systems — JW WINCO stainless steel clevis rod ends (e.g., 8NXBIS) for connecting pneumatic cylinders or actuators in automated equipment.

Clamping arm extension — JW WINCO rigid clamping arm extenders (e.g., 801.1-85-16-ST) for increasing reach on toggle clamps in custom fixtures.

JW WINCO Products

3G Electric supplies JW WINCO fully threaded t-slot nuts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
