JOHNSON CONTROLS Actuator: Dampers/VAV Boxes/Zone Valves, Floating Point with Timeout/On/Off - Non-Fail-Safe Actuators
JOHNSON CONTROLSNon-Fail-Safe Actuators

JOHNSON CONTROLS Actuator: Dampers/VAV Boxes/Zone Valves, Floating Point with Timeout/On/Off

The JOHNSON CONTROLS M9104-IGA-3S is a non-fail-safe actuator for dampers, VAV boxes, and zone valves. It operates on 24V AC with a 93° stroke and CW/CCW shaft rotation. This floating-point with timeout/on/off…

SKU 3G-OTH-67089

Brand
JOHNSON CONTROLS
Item
Actuator: Dampers/VAV Boxes/Zone Valves, Floating Point with Timeout/On/Off
Category
Non-Fail-Safe Actuators
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

JOHNSON CONTROLS
Manufacturer Part Number
M9104-IGA-3S
Type
Floating Point with Timeout/On/Off, Non-Spring Return
Input Voltage
24V AC
Stroke Degree
93°
Shaft Rotation
CW/CCW
Auxiliary Switch Included
No
Electrical Connection Type
Screw Terminals
For Use With Building Automation Systems
Building Automation System Compatible
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

JOHNSON CONTROLS Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The JOHNSON CONTROLS M9104-IGA-3S is a non-fail-safe actuator for dampers, VAV boxes, and zone valves. It operates on 24V AC with a 93° stroke and CW/CCW shaft rotation. This floating-point with timeout/on/off, non-spring-return actuator features screw terminals and is compatible with building automation systems.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is the JOHNSON CONTROLS M9104-IGA-3S actuator used for?

The JOHNSON CONTROLS M9104-IGA-3S is a non-fail-safe actuator designed for dampers, VAV boxes, and zone valves in building automation systems. It provides floating-point with timeout/on/off control for precise air or water flow regulation in HVAC applications.

What are the specifications of the JOHNSON CONTROLS M9104-IGA-3S?

The M9104-IGA-3S operates on 24V AC input voltage, has a 93° stroke, and supports CW/CCW shaft rotation. It features screw terminals for electrical connection, no auxiliary switch, and is compatible with building automation systems. It is a non-spring-return, floating-point with timeout/on/off actuator.

Where to buy the JOHNSON CONTROLS M9104-IGA-3S worldwide?

You can source the JOHNSON CONTROLS M9104-IGA-3S from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the JOHNSON CONTROLS M9104-IGA-3S actuator?

Mount the actuator securely on the damper or valve shaft, ensuring proper alignment. Connect 24V AC power to the screw terminals per the wiring diagram. Verify CW/CCW rotation matches the application. Test the floating-point control signal before commissioning. Always follow local electrical codes.
