HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size, 100 PK (MPN A3591-3CNW285). These 18-8 stainless steel inserts feature a Dry Film Lubricant finish, fine threads, and a tensile strength…

SKU 3G-OTH-528835

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A3591-3CNW285
Type
Screw-Locking, #10-32 Thread Size, 100 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Dry Film Lubricant
Thread Type
Fine
STI Tap Size
#10-32
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #10-32 Thread Size, 100 PK (MPN A3591-3CNW285). These 18-8 stainless steel inserts feature a Dry Film Lubricant finish, fine threads, and a tensile strength of 200,000 to 250,000 psi. Designed for right-hand thread repair in metal, they require an STI Tap Size of #10-32 and are supplied in inch-system packaging.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a HELI-COIL screw-locking helical insert used for?

A HELI-COIL screw-locking helical insert repairs or reinforces internal threads in metal components. The screw-locking feature resists vibration loosening, making it ideal for automotive, aerospace, and industrial applications where joint integrity is critical.

What are the specifications of the HELI-COIL A3591-3CNW285 insert?

This HELI-COIL insert has a #10-32 fine thread, right-hand direction, and 18-8 stainless steel construction with a Dry Film Lubricant finish. Tensile strength ranges from 200,000 to 250,000 psi. It requires an STI tap size of #10-32 and comes in a 100-pack for inch-system metal repair.

Where to buy HELI-COIL inserts in worldwide?

3G Electric supplies HELI-COIL inserts worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on the A3591-3CNW285 or other HELI-COIL part numbers.

How to install a HELI-COIL tanged screw-locking insert?

Drill out the damaged thread to the specified size, tap the hole using the correct STI tap (#10-32 for this insert), then use a tang-style installation tool to wind the insert into place. After installation, break off the tang with a punch. Always follow HELI-COIL's published instructions for best results.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
