HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #6-32 Thread Size, Plain - Screw-Locking Tanged Helical Inserts
HELI-COILScrew-Locking Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Screw-Locking, #6-32 Thread Size, Plain

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert with #6-32 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, is compatible…

SKU 3G-OTH-529028

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Screw-Locking, #6-32 Thread Size, Plain
Category
Screw-Locking Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
3585-06CN276S
Type
Screw-Locking, #6-32 Thread Size, Plain, 1,000 PK
Tensile Strength
200,000 to 250,000 psi
Finish Type
Plain
Thread Type
Coarse
STI Tap Size
#6-32
Thread Direction
Right Hand
Compatible Material
Metal
Material Grade/Class
18-8
System of Measurement
Inch
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a tanged tang style, screw-locking insert with #6-32 coarse thread size, plain finish, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, is compatible with metal, and comes in a 1,000 PK. This inch-system, right-hand thread insert uses an STI tap size of #6-32.

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces threads in metal. This screw-locking, tanged tang style insert for #6-32 coarse threads provides a strong, wear-resistant thread in aluminum, cast iron, or steel, preventing stripping and extending component life.

What are the specifications of the HELI-COIL 3585-06CN276S insert?

This HELI-COIL insert has a #6-32 coarse thread, right-hand direction, and 18-8 material grade. It offers a tensile strength of 200,000 to 250,000 psi, plain finish, and is compatible with metal. It comes in a 1,000-piece pack and requires an STI tap size of #6-32.

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial sourcing partner, we handle logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on the 3585-06CN276S or other HELI-COIL thread repair inserts.

How to install a HELI-COIL tanged helical insert?

To install a HELI-COIL tanged insert, drill out the damaged thread to the specified size, tap the hole using the correct STI tap (here #6-32), then use a tang-style installation tool to wind the insert into the tapped hole. After installation, break off the tang with a punch.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates

HELI-COIL Products

3G Electric supplies HELI-COIL screw-locking tanged helical inserts. We supply genuine products with in-stock availability on common SKUs, technical documentation, commissioning support, and warranty service — worldwide.
