HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, #10-24 Thread Size - Free-Running Tanged Helical Inserts
HELI-COILFree-Running Tanged Helical Inserts

HELI-COIL Helical Insert: Tanged Tang Style, Free-Running, #10-24 Thread Size

The HELI-COIL Helical Insert is a free-running tanged tang style insert with #10-24 thread size, right-hand coarse thread, and 18-8 metal construction. It features a dry film lubricant and a tensile strength range of…

SKU 3G-OTH-599123

Brand
HELI-COIL
Item
Helical Insert: Tanged Tang Style, Free-Running, #10-24 Thread Size
Category
Free-Running Tanged Helical Inserts
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

HELI-COIL
Manufacturer Part Number
A1185-3CNW190
Type
Free-Running, #10-24 Thread Size, 100 PK
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

HELI-COIL Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The HELI-COIL Helical Insert is a free-running tanged tang style insert with #10-24 thread size, right-hand coarse thread, and 18-8 metal construction. It features a dry film lubricant and a tensile strength range of 200,000 to 250,000 psi, supplied in a 100-piece pack (MPN A1185-3CNW190).

Supplied to the Philippines — compatible with 60 Hz installations. DHL Express delivery to Manila, Quezon City, Cebu, customs and duties handled door-to-door.

Frequently Asked Questions

What is a HELI-COIL helical insert used for?

A HELI-COIL helical insert repairs or reinforces tapped threads in metal. It provides a durable, free-running internal thread for #10-24 fasteners, ideal for automotive, aerospace, and industrial maintenance applications where stripped threads need restoration.

What are the specifications of the HELI-COIL A1185-3CNW190 insert?

This HELI-COIL insert is a free-running tanged tang style with #10-24 thread size, right-hand coarse thread, and 18-8 metal construction. It has a tensile strength of 200,000 to 250,000 psi, includes a dry film lubricant, and comes in a 100-piece pack (MPN A1185-3CNW190).

Where to buy HELI-COIL helical inserts worldwide?

3G Electric supplies HELI-COIL helical inserts worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver genuine HELI-COIL products like the A1185-3CNW190 to your facility, regardless of location.

How to install a HELI-COIL tanged helical insert?

To install a HELI-COIL tanged insert, drill out the damaged thread to the specified tap drill size, tap the hole with the correct HELI-COIL tap, then use a tang-style installation tool to wind the insert into place. Break off the tang after installation for a permanent thread.

Used in

Common applications for HELI-COIL
Aerospace engine repair — HELI-COIL STI taps for M12x1.75 metric threads in aluminum alloy components
Automotive transmission rebuild — HELI-COIL STI taps for 7/16-14 UNC threads in cast iron housings
Industrial pump maintenance — HELI-COIL STI taps for #10-32 UNF threads in stainless steel pump bodies
Hydraulic cylinder repair — HELI-COIL STI taps for M6x1 metric threads in steel cylinder heads
General manufacturing — HELI-COIL STI taps for 9/16-18 UNF threads in machinery base plates
